Rinnai Australia - 37 - Solar Split Systems Operating / Installation Manual Version 8-18/10/10
Sunmaster SG175 or SG215 with SGPKIT2
Items Supplied with Cylinder Items Supplied in SGPKIT2 (cont…)
1
1
PTR Valve 92501190
1
Adaptor R ¾ x Rp ½
3
3
Nipple R ¾
11
1
Pump & Controller Assembly 39001735
includes:
x 2 x ½” Kinco nut & olive
x Flow control valve 11001033
x Non return valve 27801711
x Temperature sensor lead 31002710
x Pump 30001703
x Control Box 31002703
12
1
Temperature Sensor with 2 m lead
Part of Pump and Controller Assembly
(39001735), but shown separately
for clarity in diagrams 31002710
16
2
Gas Booster Mounting Brackets
1 x tabs bent
26601098
1 x tabs unbent 26601096
Items Supplied in SGPKIT2
13
2
Elbow ¾ Rp x ¾ G flexi 21201012
5
1
¾ Kinco Olive 33001011
14
2
Fibre Washer ¾ 17401008
6
1
¾ Kinco Nut 16801018
15
1
Insulated Flexi Pipe 890 mm 11601070
8
1
Cold Inlet Copper T 11603921
17
1
Adaptor Rp ¾ x G ¾ (flexi) 16601006
-
1
Warranty booklet
15401024
-
10
Screws 22601048
-
1 RECS form
15401023
-
1
Operation and
Installation Manual
15401021

INSTALLATION & MAINTENANCE - GAS BOOSTED SYSTEMS
