Rinnai Australia - 39 - Solar Split Systems Operating / Installation Manual Version 8-18/10/10
Sunmaster SG270 with SGPKIT270
Items Supplied with Cylinder
Items Supplied in SGPKIT270 (cont…)
1
1
PTR Valve 92501192
1
Adaptor R ¾ x Rp ½
3
3
Adaptor R ¾ x Rp ¾
11
1
Pump & Controller Assembly 39001735
includes:
x 2 x ½” Kinco nut & olive
x flow control valve 11001033
x non return valve 27801711
x Temperature sensor lead 31002710
x Pump 30001703
x Control Box 31002703
Items Supplied in SGPKIT270
4
2
R ¾ Nipples 17201003
12
1
Temperature Sensor with 2 m lead
Part of Pump and Controller Assembly
(39001735), but shown separately
for clarity in diagrams 31002710
5
1
¾ Kinco Olive 33001011
13
2
Elbow ¾ Rp x ¾ G flexi 21201012
6
1
¾ Kinco Nut 16801018
14
2
Fibre Washer ¾ 17401008
7
1
Copper Tee 11603936
8
2
½ Kinco Olive 33001012
(*1 not needed)
15
1
Insulated Flexi Pipe
1080 mm
11601069
9
2
½ Kinco Nut 16801012
(*1 not needed)
10
1
Insulated Copper
Extension Pipe
11603348
16
2
Gas Booster Mounting Brackets
1 x tabs bent
26601098
1 x tabs unbent 26601096
- 1 Operation and
Installation Manual
15401030
- 3
Cable Ties 39601036
-
1
Booster and Pump Mounting
Instruction Sheet
15401031
- 12
Screws 22601048
-
1
Gas Booster
Mounting Template
15401034
-
1 RECS form
15401023
-
1 Warranty booklet
15401024
-
1 Standardsmark Sticker
15802091
-1
Saddle Clamp 27201015
*This kit is used for a variety of installations. Items marked with an * are not needed for this particular installation
