Rinnai SUNMASTER - Page 45

Rinnai Australia - 43 - Solar Split Systems Operating / Installation Manual Version 8-18/10/10
FF
Prestige MKII Gas with USKIT1
Items Supplied with Cylinder
Items Supplied in USKIT1
1
1
PTR Valve 11004784
1
Adaptor ¾ R to ½ Rp 19801004
3
2
T ¾ Rp 19001011
8
1
Cold Inlet Copper T 11603921
4
2
Nipple R ¾ 17201005
9
1
G ¾ (comp) x R ¾ Union 32201713
5
1
Adaptor R ¾ to G ¾ (flexi) 17201006
6
2
Fibre Washer ¾ 17401008
11
1
Pump & Controller Assembly 39001735
includes:
x 2 x ½” Kinco nut & olive
x flow control valve 11001033
x non return valve 27801711
x Temperature sensor lead 31002710
x Pump 30001703
x Control Box 31002703
7
1
Insulated Flexi Pipe
1080 mm
11601069
10
1
Temperature Sensor
Sheath 250 mm
10204721
12
1
Temperature Sensor with 2 m lead
Part of Pump and Controller Assembly
(39001735), but shown separately
for clarity in diagrams 31002710
13
1
Elbow ¾ Rp x ¾ G flexi 21201012
-
6
Screws 22601048
-
1
Operation and
Installation Manual
15401021
-
1
Warranty booklet
15401024
14
2
Gas Booster Mounting Brackets
1 x tabs bent
26601098
1 x tabs unbent 26601096
-
1
RECS form
15401023
8
Screws 22601048
1
Gas Booster Mounting
Template (Prestige Gas)
15401040

INSTALLATION & MAINTENANCE - GAS BOOSTED SYSTEMS
