Rinnai SUNMASTER User Manual

Rinnai Australia - 51 - Solar Split Systems Operating / Installation Manual Version 8 - 18/10/10
Sunmaster SE160, SE200 or SE315 with USKIT1
Items Supplied with Cylinder
Items Supplied in USKIT1
1
1
PTR Valve
SE160,SE200 92501190
SE315 92501192
1
Adaptor R¾ x Rp½
8
1
Cold Inlet Copper T 11603921
3
3
Adaptor R¾ x Rp¾
9
1
G3/4 (Comp) x R ¾ union 32201713
11
1
Pump & Controller Assembly 39001735
includes:
x 2 x ½” Kinco nut & olive
x flow control valve 11001033
x non return valve 27801711
x Temperature sensor lead 31002710
x Pump 30001703
x Control Box 31002703
12
1
Temperature Sensor with 2 m lead
Part of Pump and Controller Assembly
(39001735), but shown separately
for clarity in diagrams 31002710
-
6
Screws 22601048
-
1
Operation and
Installation Manual
15401021
-
1 Warranty booklet
15401024
-
1 RECS form
15401023
