Rinnai Australia - 53 - Solar Split Systems Operating / Installation Manual Version 8 - 18/10/10
Prestige MkII Electric with USKIT1
Items Supplied with Cylinder
Items Supplied in USKIT1
1
1
PTR Valve 11004784
1
Hot outlet T 19001018
8
1
Cold Inlet Copper T 11603921
3
1
T ¾ Rp 19001011
9
1
G3/4 (Comp) x R ¾ union 32201713
4
1
Nipple R ¾ 17201005
10
1
250 mm Sheath
Thermocouple
10204721
11
1
Pump & Controller Assembly 39001735
includes:
x 2 x ½” Kinco nut & olive
x flow control valve 11001033
x non return valve 27801711
x Temperature sensor lead 31002710
x Pump 30001703
x Control Box 31002703
12
1
Temperature Sensor with 2 m lead
Part of Pump and Controller Assembly
(39001735), but shown separately
for clarity in diagrams 31002710
- 6
Screws 22601048
- 1
Operation and
Installation Manual
15401021
- 1 Warranty booklet
15401024
- 1 RECS form 15401023
