Rinnai V Model Series User Manual

26 V53De Manual
Temperature Opons Without a Temperature Controller
The default temperature seng for this appliance installed without a temperature controller is 120° F (49° C).
If desired, the temperature seng can be changed to 140° F (60° C), as well as other temperature increments
by push buon adjustments, as described below.
1
2
3
4
5
PCB Interface Layout and Funcons
1. Push Buon 1 (PB1) - White
Data transfer buon for PCB replacement.
2. Push Buon 2 (PB2) - Black
MODE buon - places PCB in programming mode.
3. Push Buon 3 (PB3) - White
MENU buon - cycles through available menus 1, 2, 3, 4, 5 and 6
(see table below).
4. Push Buon 4 (PB4) - White
VALUE buon - cycles through available menu values
(see table below).
5. Push Buon 5 (PB5) - White
Forced High/Low selecon rate seng
6. LED Digital Display
Displays MENU (1, 2, etc.), VALUE (A, B, etc.) and Forced Low/High status
(L or H).
Dip Switch detail when
viewed from the front
Menu #
Menu
Descripon
Value
A b C b
1 Gas Type LPG NG
2 Model Type 1620
3 Fixed Temperatures
120°F
48.9°C
140°F
60°C
4 Max Temperature Seng of Controller(s)
120°F
48.9°C
140°F
60°C
5 OFF Water Flow Rate
+5°F
+3°C
+11°F
+6°C
6 Adjustment due to piping heat loss
+0°F
+0°C
+2°F
+1°C
+4°F
+2°C
+5°F
+3°C
6
Programming Parameters
