Applicable Standards:
EMC IEC 61326
Immunity IEC 61000-4-3.
10V/m min – Level 3
industrial Low level
Safety IEC 61010-1-2010 ,
Permanently
connected use
IP for water & dust IEC 60529
Pollution degree: 2
Installation category: III
Isolation
High Voltage Test 3.3 kV AC, 50 Hz for
1 minute between all
Electrical circuits.
Environmental
Operating temperature -10 to +55°C
Storage temperature -20 to +65°C
Relative humidity 0... 90% non
condensing
Warm up time Minimum 3 minute
Shock 15g in 3 planes
Vibration 10... 150.... 10 Hz,
0.15mm amplitude
Enclosure front IP54
Enclosure back IP20
Enclosure
Style 96mm x 96mm DIN
Quadratic
Material Polycarbonate
Housing
Terminals Screw-type terminals
Depth < 60 mm
Weight 300 grams Approx.
The Information contained in these installation instructions is for use only by installers trained to make electrical power
installations and is intended to describe the correct method of installation for this product. However, Company has no
control over the eld conditions which inuence product installation.
It is the user's responsibility to determine the suitability of the installation method in the user's eld conditions. Company
only obligations are those in Company standard Conditions of Sale for this product and in no case will Company be liable
for any other incidental, indirect or consequential damages arising from the use or misuse of the products.
25
