V2.7 2017-09-28
www.risinghf.com
ST Nucleo LoRa GW User Guide
RisingHF
23
7.3 RF performance measurement
Table 7-2 below shows the RF performance in conductive test. Please note that, there is no external
PA refer to Semtech’s reference design, so the RF power is output from SX125x FEM directly. The
maximum output power normally would be 6-7dBm type in different band.
Table 7-2 RF performance
Band
Frequency
TX op max/dBm
Harmonic/dBm
Sensitivity/dBm
HF
915MHz
6dBm type
Below -56dBm
SF12 125kHz
-140dBm
SF11 125kHz
-137dBm
SF10 125kHz
-134dBm
SF9 125kHz
-131dBm
SF8 125kHz
-128dBm
SF7 125kHz
-124dBm
