12 PUB. NO. FASTRAXC FEBRUARY 2008
FASTRAX
™
ELECTRICAL INSTALLATION
FIGURE 21 - CONTROL BOX
Incoming Power
Terminals F1, F2, F3
Incoming Power
Terminals F1, F2
Serial # Label
Serial #
Label
i-COMM Controller
