RITE-HITE FASTRAX User Manual

PUB. NO. FASTRAXC FEBRUARY 2008 5
FASTRAX
™
LOWER TRACK INSTALLATION
FIGURE 5 - LOWER TRACK
Ordered Door Width
Lower Track
FIGURE 3 - LOWER TRACK W/O POLY LUMBER
FasTrax
1/2 Ordered Door
Width + 1/4"
(+ 1/16", -0")
4 1/2”
Ref.
Drive Tube
Mounting
Bracket
Photoeye
Junction Box
Mounting
Holes
FIGURE 4 - THRU-BOLT
FIGURE 3B - LOWER TRACK W/ POLY LUMBER
FIGURE 3C - FR LOWER TRACK W/ POLY LUMBER
Poly Lumber
Poly Lumber
4 3/4"
Ref.
Door Opening Width
FasTrax Ordered Door
Width + 1/2" (+ 1/8", -0")
FIGURE 3A - FR LOWER TRACK W/O POLY LUMBER
FasTrax FR
1/2 Ordered Door
Width + 4 1/2"
(+ 1/16", -0")
4 3/4"
Ref.
Door Opening Width
FasTrax FR Ordered Door
Width + 9" (+ 1/8", -0")
8 3/4"
Ref.
FasTrax
1/2 Ordered Door
Width + 1/4"
(+ 1/16", -0")
7 1/2”
Ref.
6 1/4"
Ref.
Door Opening Width
FasTrax Ordered Door
Width + 1/2" (+ 1/8", -0")
FasTrax FR
1/2 Ordered Door
Width + 4 1/2"
(+ 1/16", -0")
6 1/4"
Ref.
Door Opening Width
FasTrax FR Ordered Door
Width + 9" (+ 1/8", -0")
8 3/4"
Ref.
FIGURE 7 - RADIAL DOOR
Rollers Will Need to
be Removed Prior to
Curtain Installation
90°
O.D.W. + 1/4"
O.D.W. + 1/4"
Support
Bracket
Area Behind
Wall Mounting
Plates, MUST
be Solid
90°
90°
90°
90°
Caulk
Caulk
Caulk
Caulk
