Rittal PMC12 User Manual

Technical Specifications
UPS-Manual
30
EN
Model 1KVA 2KVA 3KVA
(Bypass Mode)
<105% continuous
>106% ~ 120% for 250 seconds shuts down
> 121% ~ 130% for 125 seconds shuts down
>131% ~ 135% for 50 seconds shuts down
>136% ~ 145% for 20 seconds shuts down
>146% ~ 148% for 5 seconds shuts down
>149% ~ 157% for 2 seconds shuts down
>158% ~ 176% for 1 seconds shuts down
>177% ~ 187% for 0,32 seconds shuts down
>188% for 0,16 seconds shuts down
Buzzer continuously alarms.
Short Circuit
Bypass mode : Input Fuse/Input Breaker
Normal Mode: Output Breaker/Electronic Circuit
Battery Mode: Output Breaker/Electronic Circuit
Battery ABDM
EPO UPS shuts down immediately
Normal Mode Transfer to Bypass Mode
Over
Temperature
Battery Mode UPS shuts down immediately
Audible Alarm
Battery Mode Sounding once every 1,5 seconds
Low Battery Sounding once every 0,2 seconds
Overload Sounding once every 3 second
Fault Continuously Sounding (or Sounding once every 3 second)
Physical
Dimensions mm (HxWxD)
PMC12 Standard Design
88(2U)x440x 650 88.8(2U)x440x 650
Dimensions mm (HxWxD)
PMC12 compact Design
88(2U)x440x405
176(4U)x440x420 176(4U)x440x420
Weights
15,7kg (34,5Ib) 29,4kg (64,7Ib) 29,7kg (65,3Ib)
Input Connection 10A, IEC 320-C14 10A, IEC 320-C14 16A, IEC 320-C20
Output Connection
230V
(6) 10A,IEC 320-C13
(4) 10A,IEC 320-C13
(1) 16A,IEC 320-C19
Environmental
Operation Temperature 0 - 40 °C
Noise Level < 50 dBA
Relative Humidity 0 to 90% (Without condensation)
Interface
Interface Type 1 *USB port+ 1*RS-232 port
SNMP Power management from SNMP manager and Web browser
Compatible platforms Windows 95/98/NT/2000/XP/Vista, Novell NetWare, Linux, etc.
Standards and Certification
Safety IEC/EN 62040-1-1,IEC 60950-1
Performance IEC/EN 62040-3
EMC
IEC/EN62040-2 Class A, FCC Part 15 Subpart B Class A, IEC/EN55011, CISPR11,
IEC61000-4-2/-3/-4/-5, IEC61000-2-2, IEC61000-3-2/-3
Markings CE, WEEE
