Rittal VX IT Series User Manual

54
Schranksystem VX IT / VX IT enclosure system / Baies VX IT
1
4
2.2
6.1
7
2.1
5
3
6.2
8
5 x 12
5 x 12
5 x 12
5 x 12
4. Montage und Aufstellung
4. Assembly and siting
4. Montage et implantation
TX30
M
A
= 5 Nm
M
A
= 5 Nm
M
A
= 5 NmM
A
= 5 Nm
F
F
F
F
F
F
F
F
F
F
F
2 3
6 7
6 7
5 8
5 8
1 4
2 3
1 4
4.3.8 Aufstellung vorbereiten
4.3.8 Preparing for installation
4.3.8 Préparer la mise en place
Tiefenverstellung der 19˝-Ebene,
Rackbreite 600 mm, Racktiefe 600/800/1000 mm
Depth adjustment of the 482.6 mm (19˝) level,
rack width 600 mm, rack depth 600/800/1000 mm
Réglage en profondeur du plan 19˝,
largeur de baie 600 mm, profondeur de baie 600/800/1000 mm
Profi lschienensystem standard oder dynamic
Mounting angle system, standard or dynamic
Montants « standard » ou « dynamic »

Rittal VX IT Series Specifications

General

Color	RAL 7035
Protection category	IP55
Width	600 mm
Depth	1000 mm
Weight	Varies by model
Door Type	Single door
