RKC INSTRUMENT CB100 Series User Manual

Temperature Controller Driver
GP-Pro EX Device/PLC Connection Manual
110
1A)
• 1:1 Connection
• 1:n Connection
GP-4107 (COM1)
GP-4*03T
*5
(COM2)
GP-4203T (COM1)
1H User-created cable
The cable length
must be 1200m or
less.
GP4000
*6
(COM2)
GP-4201T (COM1)
SP5000 (COM1/2)
1I
RS-422 terminal block conversion adapter by Pro-face
PFXZCBADTM1
*7
+
User-created cable
The cable length
must be 1200m or
less.
1B User-created cable
LT-4*01TM (COM1)
LT-Rear Module (COM1) 1J
RJ45 RS-485 Cable (5m) by Pro-face
PFXZLMCBRJR81
The cable length
must be 200m or
less.
*1 All GP3000 models except AGP-3302B
*2 All ST models except AST-3211A and AST-3302B
*3 All GP3000 models except GP-3200 series and AGP-3302B
*4 Only the COM port which can communicate by RS-422/485 (2 wire) can be used.
 IPC COM Port (page 9)
*5 Except GP-4203T
*6 All GP4000 models except GP-4100 series, GP-4*01TM, GP-4201T and GP-4*03T
*7 When using a Terminal Block Conversion Adapter (CA3-ADPTRM-01) instead of the RS-422 Terminal Block
Conversion Adapter, refer to Cable Diagram 1A.
Display
(Connection Port)
Cable Notes
RDB
SDB
SG
FG
CA3-ADPCOM-01
CA3-ADPTRM-01
RDA
SDA
T/R(B)
T/R(A)
SG
Termination
resistance
120Ω (1/2W)
Termination
resistance
120Ω (1/2W)
Display
Display
External Device
Terminal block
Shield
Signal name
Signal name
User-created cable
RDB
SDB
SG
FG
CA3-ADPCOM-01
CA3-ADPTRM-01
RDA
SDA
T/R(B)
T/R(A)
SG
T/R(B)
T/R(A)
SG
Termination
resistance
120Ω (1/2W)
Termination
resistance
120Ω (1/2W)
Display
Display
External Device
Terminal block
External Device
Terminal block
Shield
Shield
Signal name
Signal name
Signal name
User-created cable
