RKC INSTRUMENT CB100 Series - 6.9 SR Mini HG(H-PCP-J) Series

Temperature Controller Driver
GP-Pro EX Device/PLC Connection Manual
244
6.9 SR Mini HG(H-PCP-J) Series
This address can be specified as system data area.
Device Bit Address Word Address
32
bits
Notes
Communication identifier
01/0000.0-01/00D4.F 01/0000-01/00D4
*1 *2 *3
*1 There are cases for which writing is not available depending on the device address. Check the
identifying attributes of the external device’s manual before use.
*2 When bit is written, the indicator reads the corresponding word address of external device, assign a bit
to the read word address, and return to the external device. There are cases when correct data cannot
be written if the word address is written using a ladder program, while the indicator reads data of the
external device and sends it back.
*3 It is necessary to specify the channel number for a module supported by the identifier about SR-Mini-
HG (H-PCP-A/B) and SR-Mini-HG (H-PCP-J) Series.
02/0000.0-02/00D4.F 02/0000-02/00D4
03/0000.0-03/00D4.F 03/0000-03/00D4
04/0000.0-04/00D4.F 04/0000-04/00D4
05/0000.0-05/00D4.F 05/0000-05/00D4
06/0000.0-06/00D4.F 06/0000-06/00D4
07/0000.0-07/00D4.F 07/0000-07/00D4
08/0000.0-08/00D4.F 08/0000-08/00D4
09/0000.0-09/00D4.F 09/0000-09/00D4
10/0000.0-10/00D4.F 10/0000-10/00D4
11/0000.0-11/00D4.F 11/0000-11/00D4
12/0000.0-12/00D4.F 12/0000-12/00D4
13/0000.0-13/00D4.F 13/0000-13/00D4
14/0000.0-14/00D4.F 14/0000-14/00D4
15/0000.0-15/00D4.F 15/0000-15/00D4
16/0000.0-16/00D4.F 16/0000-16/00D4
17/0000.0-17/00D4.F 17/0000-17/00D4
18/0000.0-18/00D4.F 18/0000-18/00D4
19/0000.0-19/00D4.F 19/0000-19/00D4
20/0000.0-20/00D4.F 20/0000-20/00D4
::
95/0000.0-95/00D4.F 95/0000-95/00D4
96/0000.0-96/00D4.F 96/0000-96/00D4
01/0000
Channel number (Setting range: 01 to 96)
