RKC INSTRUMENT CB100 Series - Page 245

Temperature Controller Driver
GP-Pro EX Device/PLC Connection Manual
245
<Communication identifier list>
Address Identifier Description
00 M1
Temperature measured value (PV) [H-TIO-
, H-CIO-A] / Motor speed measured value
[H-SIO-A]
01 AA Alarm 1 status [H-TIO-
, H-CIO-A, H-SIO-A]
02 AB Alarm 2 status [H-TIO-
, H-CIO-A, H-SIO-A]
03 B1 Burnout status [H-TIO-
, H-CIO-A, H-SIO-A]
04 O1 Heat-side manipulated output value [H-TIO-
, H-CIO-A]
05 O2 Cool-side manipulated output value [H-TIO-
, H-CIO-A]
06 AC Heater break alarm status [H-TIO-A/C/D, H-CIO-A]
07 M3 Current transformer input measured value 1 [H-TIO-A/C/D]
08 M4 Current transformer input measured value 2 [H-CT-A]
09 MS Set value monitor [H-TIO-
, H-CIO-A, H-SIO-A]
0A HE Temperature rise completion status [H-TIO-
, H-CIO-A]
0B ER Error code [H-PCP-J]
0C G1 PID/AT transfer [H-TIO-
, H-CIO-A, H-SIO-A]
0D S1 Temperature set value (SV) [H-TIO-
, H-CIO-A] / Motor speed set value [H-SIO-A]
0E P1 Heat-side proportional band [H-TIO-
, H-CIO-A, H-SIO-A]
0F P2 Cool-side proportional band [H-TIO-
, H-CIO-A]
10 I1 Integral time [H-TIO-
, H-CIO-A, H-SIO-A]
11 D1 Derivative time [H-TIO-
, H-CIO-A, H-SIO-A]
12 V1 Overlap/deadband [H-TIO-
, H-CIO-A]
13 CA Control response parameters [H-TIO-
, H-CIO-A, H-SIO-A]
14 A1 Alarm 1 set value [H-TIO-
, H-CIO-A, H-SIO-A]
15 A2 Alarm 2 set value [H-TIO-
, H-CIO-A, H-SIO-A]
16 A3 Heater break alarm set value 1 [H-TIO-A/C/D]
17 A4 Heater break alarm set value 2 [H-CT-A]
18 EI Operation mode transfer [H-TIO-
, H-CIO-A, H-SIO-A]
19 T0 Heat-side proportioning cycle time [H-TIO-
, H-CIO-A]
1A T1 Cool-side proportioning cycle time [H-TIO-
, H-CIO-A]
1B PB PV bias [H-TIO-
, H-CIO-A, H-SIO-A]
1C SR Control RUN/STOP transfer [H-PCP-J]
1D IN Initial setting mode [H-PCP-J]
1E ZA Memory area number [H-TIO-
, H-CIO-A, H-SIO-A]
1F AR Alarm interlock release [H-TIO-
, H-CIO-A, H-TI-, H-AI-]
20 J1 Auto/Manual transfer [H-TIO-
, H-CIO-A]
21 ON Manual output value [H-TIO-
, H-CIO-A]
22 HD Temperature rise completion range [H-TIO-
, H-CIO-A]
23 HS Temperature rise completion trigger [H-TIO-
, H-CIO-A]
24 T3 Temperature rise completion soak time [H-TIO-
, H-CIO-A]
25 M5 AI measured value [H-AI-A/B]
26 AD AI alarm 1 status [H-AI-A/B]
27 AE AI alarm 2 status [H-AI-A/B]
28 A5 AI alarm 1 set value [H-AI-A/B]
29 A6 AI alarm 2 set value [H-AI-A/B]
2A JI AI zero point correction [H-AI-A/B]
2B JJ AI full scale correction [H-AI-A/B]
2C NJ AI operation mode transfer [H-AI-A/B]
2D AP Control loop break alarm (LBA) status [H-TIO-
, H-CIO-A]
2E HP LBA use selection [H-TIO-
, H-CIO-A]
2F C6 LBA time [H-TIO-
, H-CIO-A]
30 V2 LBA deadband [H-TIO-
, H-CIO-A]
31 M6 AO output value monitor [H-AO-A/B]
32 S6 AO output set value [H-AO-A/B]
