Temperature Controller Driver
GP-Pro EX Device/PLC Connection Manual
214
6.1 CB Series
This address can be specified as system data area.
<Communication identifier list>
Device Bit Address Word Address
32
bits
Notes
Communication identifier 0000.00-0038.F 0000-0038
*1
*2
*1 There are cases for which writing is not available depending on the device address. Check the
identifying attributes of the external device's manual before use.
*2 When bit is written, the indicator reads the corresponding word address of external device, assign
a bit to the read word address, and return to the external device. There are cases when correct data
cannot be written if the word address is written using a ladder program, while the indicator reads
data of the external device and sends it back.
Address Identifier Description
00 M1 Measured value (PV)
01 M2 Current transformer input 1
02 M3 Current transformer input 2
03 AA Alarm 1 status
04 AB Alarm 2 status
05 B1 Burnout
06 S1 Set value (SV)
07 A1 Alarm 1 setting
08 A2 Alarm 2 setting
09 A3 Heater break alarm 1 setting
0A A4 Heater break alarm 2 setting
0B A5 Control loop break alarm (LBA) setting
0C A6 LBA deadband
0D G1 Autotuning (AT)
0E G2 Self-tuning (ST)
0F P1 Heat-side proportional band
10 I1 Integral time
11 D1 Derivative time
12 W1 Anti-reset windup
13 T0 Heat-side proportioning cycle
14 P2 Cool-side proportional band
15 V1 Overlap/deadband
16 T1 Cool-side proportioning cycle
17 PB PV bias
18 LK Set data lock function
19 SR RUN/STOP transfer
1A ER Error code
1B IO Initialization mode selection
1C IP Setting necessary code [Cod]
1D XI Input type selection [SL1]
1E XQ Engineering unit and cooling type selection [SL2]
1F LV
Heater break alarm (HBA), control loop break alarm (LBA),special specification, or
control loop break alarm (LBA) output selection [SL3]
20 XA First alarm (ALM1) type or First alarm (ALM1) with hold action selection [SL4]
21 XB Second alarm (ALM2) type or Second alarm (ALM2) with hold action selection [SL5]
To Next Page
