Temperature Controller Driver
GP-Pro EX Device/PLC Connection Manual
227
6.4 MA Series
This address can be specified as system data area.
<Communication identifier list>
Device Bit Address Word Address
32
bits
Notes
Communication identifier 0000.0-002A.F 0000-002A
*1
*2
*1 There are cases for which writing is not available depending on the device address. Check the
identifying attributes of the external device’s manual before use.
*2 When bit is written, the indicator reads the corresponding word address of external device, assign
a bit to the read word address, and return to the external device. There are cases when correct data
cannot be written if the word address is written using a ladder program, while the indicator reads
data of the external device and sends it back.
Address Identifier Description
00 M1 Measured value (PV)
01 M2 Current transformer 1 input value
02 M3 Current transformer 2 input value
03 MS Set value monitor
04 B1 Burnout
05 AA Alarm 1 status
06 AB Alarm 2 status
07 AC Alarm 3 status
08 AJ Output status
09 O1 Manipulated output value
0A O2 Cool-side manipulated output value
0B ER Error code
0C L1 DI status
0D ZA Memory area number selection
0E S1 Set value (SV)
0F A1 Alarm 1
10 N1 Control loop break alarm deadband (LBD)
11 A2 Alarm 2
12 N2 Heater break alarm 2 (HBA2)
13 A3 Alarm 3
14 P1 Proportional band
15 P2 Cool-side proportional band
16 I1 Integral time
17 D1 Derivative time
18 W1 Anti-reset windup
19 V1 Overlap/deadband
1A HH Setting change rate limiter
1B EI Used/unused of channels
1C SR RUN/STOP transfer
1D G1 PID/AT selection
1E PB PV bias
1F F1 Digital filter
20 T0 Proportioning cycle time
21 T1 Cool-side proportioning cycle time
22 TL Scan interval time
To Next Page
