Temperature Controller Driver
GP-Pro EX Device/PLC Connection Manual
215
22 CA Control action type selection [SL6]
23 Z1 Energized/de-energized alarm selection, special specification selection 1 [SL7]
24 Z2 Special specification selection 2 [SL8]
25 Z3 Special specification selection 3 [SL9]
26 DH Option selection [SL10]
27 XC SV alarm type selection [SL11]
28 XV Setting limiter (high limit) [SLH]
29 XW Setting limiter (low limit) [SLL]
2A XU Setting the position of decimal point [PGdP]
2B MH Differential gap setting of ON/OFF action [oH]
2C HA Differential gap setting of first alarm (ALM1) [AH1]
2D HB Differential gap setting of second alarm (ALM2) [AH2]
2E XR CT ratio setting [CTr]
2F F1 Digital filter setting [dF]
30 GH Time factor assumed to be safe [STTM]
31 PU Factor to calculate proportional band [STPK]
32 IU Factor to calculate integral time [STIK]
33 IL Integral time limiter [ILIM]
34 HP Holding peak ambient temperature [TCJ]
35 UT Operating time display unit (Upper digits) [WTH]
36 UU Operating time display unit (Lower digits) [WTL]
37 EB EEPROM storage mode
38 EM EEPROM storage state
• Setting "Use system data area" to GP-Pro EX system area result in improper
operation. Do not set "Use system data area."
• System area setting that can be used for the temperature controller is reading area size only. Please
refer to the GP-Pro EX Reference Manual for system data area.
Cf. GP-Pro EX Reference Manual "LS Area (Direct Access Method Area)"
• Please refer to the precautions on manual notation for icons in the table.
"Manual Symbols and Terminology"
• Even if non-existing address is used, there are cases when read error is not indicated. In this case,
zero (0) is kept for read out data. On the other hand, writing error is indicated.
