RKC INSTRUMENT CB100 Series User Manual

Temperature Controller Driver
GP-Pro EX Device/PLC Connection Manual
123
3F)
• 1:1 Connection
• 1:n Connection
RDB
SDB
SG
FG
PFXZCBADTM1
RDA
SDA
T(B)
T(A)
R(B)
R(A)
SG
External Device
Terminal block
Shield
Display
Signal name Signal name
Termination
resistance
120Ω (1/2W)
Termination
resistance
120Ω (1/2W)
Termination
resistance
120Ω (1/2W)
Termination
resistance
120Ω (1/2W)
Display
User-created cable
RDB
SDB
SG
FG
PFXZCBADTM1
RDA
SDA
T(B)
T(A)
R(B)
R(A)
SG
T(B)
T(A)
R(B)
R(A)
SG
External Device
Terminal block
External Device
Terminal block
Shield Shield
Display
Signal name Signal name Signal name
Termination
resistance
120Ω (1/2W)
Termination
resistance
120Ω (1/2W)
Termination
resistance
120Ω (1/2W)
Termination
resistance
120Ω (1/2W)
Display
User-created cable
