RKC INSTRUMENT CB100 Series User Manual

Temperature Controller Driver
GP-Pro EX Device/PLC Connection Manual
141
Cable Diagram 6
Display
(Connection Port)
Cable Notes
GP3000
*1
(COM1)
AGP-3302B (COM2)
GP-4*01TM (COM1)
ST
*2
(COM2)
LT3000 (COM1)
IPC
*3
*1 All GP3000 models except AGP-3302B
*2 All ST models except AST-3211A and AST-3302B
*3 Only the COM port which can communicate by RS-422/485 (4 wire) can be used.
 IPC COM Port (page 9)
6A
COM port conversion adapter by Pro-face
CA3-ADPCOM-01
+
Terminal block conversion adapter by Pro-face
CA3-ADPTRM-01
+
User-created cable
The cable length must
be 1200m or less.
6B User-created cable
GP3000
*4
(COM2)
*4 All GP3000 models except GP-3200 series and AGP-3302B
6C
Online adapter by Pro-face
CA4-ADPONL-01
+
Terminal block conversion adapter by Pro-face
CA3-ADPTRM-01
+
User-created cable
The cable length must
be 1200m or less.
6D
Online adapter by Pro-face
CA4-ADPONL-01
+
User-created cable
GP-4106 (COM1) 6E User-created cable
The cable length must
be 1200m or less.
GP4000
*5
(COM2)
GP-4201T (COM1)
SP5000 (COM1/2)
*5 All GP4000 models except GP-4100 series, GP-4*01TM, GP-4201T and GP-4*03T
6F
RS-422 terminal block conversion adapter by Pro-face
PFXZCBADTM1
*6
+
User-created cable
*6 When using a Terminal Block Conversion Adapter (CA3-ADPTRM-01) instead of the RS-422 Terminal Block
Conversion Adapter, refer to Cable Diagram 6A.
The cable length must
be 1200m or less.
6B User-created cable
