Temperature Controller Driver
GP-Pro EX Device/PLC Connection Manual
164
Cable Diagram 9
Display
(Connection Port)
Cable Notes
GP3000
*1
(COM1)
AGP-3302B (COM2)
GP-4*01TM (COM1)
ST
*2
(COM2)
LT3000 (COM1)
*1 All GP3000 models except AGP-3302B
*2 All ST models except AST-3211A and AST-3302B
9A
COM port conversion adapter by Pro-face
CA3-ADPCOM-01
+
Terminal block conversion adapter by Pro-face
CA3-ADPTRM-01
+
User-created cable
The cable length must
be 1200m or less.
9B User-created cable
GP3000
*3
(COM2)
*3 All GP3000 models except GP-3200 series and AGP-3302B
9C
Online adapter by Pro-face
CA4-ADPONL-01
+
Terminal block conversion adapter by Pro-face
CA3-ADPTRM-01
+
User-created cable
The cable length must
be 1200m or less.
9D
Online adapter by Pro-face
CA4-ADPONL-01
+
User-created cable
IPC
*4
*4 Only the COM port which can communicate by RS-422/485 (2 wire) can be used.
IPC COM Port (page 9)
9E
COM port conversion adapter by Pro-face
CA3-ADPCOM-01
+
Terminal block conversion adapter by Pro-face
CA3-ADPTRM-01
+
User-created cable
The cable length must
be 1200m or less.
9F User-created cable
GP-4106 (COM1) 9G User-created cable
The cable length must
be 1200m or less.
GP-4107 (COM1)
GP-4*03T
*5
(COM2)
GP-4203T (COM1)
*5 Except GP-4203T
9H User-created cable
The cable length must
be 1200m or less.
GP4000
*6
(COM2)
GP-4201T (COM1)
SP5000 (COM1/2)
*6 All GP4000 models except GP-4100 series, GP-4*01TM, GP-4201T and GP-4*03T
9I
RS-422 terminal block conversion adapter by Pro-face
PFXZCBADTM1
*7
+
User-created cable
*7 When using a Terminal Block Conversion Adapter (CA3-ADPTRM-01) instead of the RS-422 Terminal Block
Conversion Adapter, refer to Cable Diagram 9A.
The cable length must
be 1200m or less.
9B User-created cable
LT-4*01TM (COM1)
LT-Rear Module (COM1) 9J
RJ45 RS-485 Cable (5m) by Pro-face
PFXZLMCBRJR81
The cable length must
be 200m or less.
To Next Page
