RKC INSTRUMENT CB100 Series User Manual

Temperature Controller Driver
GP-Pro EX Device/PLC Connection Manual
181
Cable Diagram 13
Display
(Connection Port)
Cable Remarks
GP3000
*1
(COM1)
AGP-3302B (COM2)
GP-4*01TM (COM1)
ST
*2
(COM2)
LT3000 (COM1)
*1 All GP3000 models except AGP-3302B
*2 All ST models except AST-3211A and AST-3302B
13A
COM port conversion adapter by Pro-face
CA3-ADPCOM-01
+
Terminal block conversion adapter by Pro-face
CA3-ADPTRM-01
+
User-created cable
Cable length:1200m or less
13B User-created cable
GP3000
*3
(COM2)
*3 All GP3000 models except GP-3200 and AGP-3302B
13C
Online adapter by Pro-face
CA4-ADPONL-01
+
Terminal block conversion adapter by Pro-face
CA3-ADPTRM-01
+
User-created cable
Cable length:1200m or less
13D
Online adapter by Pro-face
CA4-ADPONL-01
+
User-created cable
IPC
*4
*4 Only the COM port which can communicate by RS-422/485 (2wire) can be used.
 IPC COM Port (page 9)
13E
COM port conversion adapter by Pro-face
CA3-ADPCOM-01
+
Terminal block conversion adapter by Pro-face
CA3-ADPTRM-01
+
User-created cable
Cable length:1200m or less
13F User-created cable
GP-4106 (COM1) 13G User-created cable Cable length:1200m or less
GP-4107 (COM1)
GP-4*03T
*5
(COM2)
GP-4203T (COM1)
*5 Except GP-4203T
13H User-created cable Cable length:1200m or less
GP4000
*6
(COM2)
GP-4201T (COM1)
SP5000 (COM1/2)
*6 All GP4000 models except GP-4100 series, GP-4*01TM, GP-4201T and GP-4*03T
13I
RS-422 terminal block conversion adapter by Pro-face
PFXZCBADTM1
*7
+
User-created cable
*7 When using a Terminal Block Conversion Adapter (CA3-ADPTRM-01) instead of the RS-422 Terminal Block
Conversion Adapter, refer to Cable Diagram 13A.
Cable length:1200m or less
13B User-created cable
LT-4*01TM (COM1)
LT-Rear Module (COM1) 13J
RJ45 RS-485 Cable (5m) by Pro-face
PFXZLMCBRJR81 Cable length:200m or less
