RKC INSTRUMENT CB100 Series User Manual

Temperature Controller Driver
GP-Pro EX Device/PLC Connection Manual
192
Cable Diagram 14
Display
(Connection Port)
Cable Remarks
GP3000
*1
(COM1)
AGP-3302B (COM2)
GP-4*01TM (COM1)
ST
*2
(COM2)
LT3000 (COM1)
IPC
*3
*1 All GP3000 models except AGP-3302B
*2 All ST models except AST-3211A and AST-3302B
14A
COM port conversion adapter by Pro-face
CA3-ADPCOM-01
+
Terminal block conversion adapter by Pro-face
CA3-ADPTRM-01
+
User-created cable
+
Connection cable from RKC INSTRUMENT INC.
*5
W-BF-02
Cable length:
1200m or less
14B
User-created cable
+
Connection cable from RKC INSTRUMENT INC.
*5
W-BF-02
GP3000
*4
(COM2)
14C
Online adapter by Pro-face
CA4-ADPONL-01
+
Terminal block conversion adapter by Pro-face
CA3-ADPTRM-01
+
User-created cable
+
Connection cable from RKC INSTRUMENT INC.
*5
W-BF-02
Cable length:
1200m or less
14D
Online adapter by Pro-face
CA4-ADPONL-01
+
User-created cable
+
Connection cable from RKC INSTRUMENT INC.
*5
W-BF-02
GP-4106 (COM1) 14E
User-created cable
+
Connection cable from RKC INSTRUMENT INC.
*5
W-BF-02
Cable length:
1200m or less
GP4000
*6
(COM2)
GP-4201T (COM1)
SP5000 (COM1/2)
14F
RS-422 terminal block conversion adapter by Pro-face
PFXZCBADTM1
*7
+
User-created cable
+
Connection cable from RKC INSTRUMENT INC.
*5
W-BF-02
Cable length:
1200m or less
14B
User-created cable
+
Connection cable from RKC INSTRUMENT INC.
*5
W-BF-02
