RKC INSTRUMENT CB100 Series User Manual

Temperature Controller Driver
GP-Pro EX Device/PLC Connection Manual
200
GP-4106 (COM1) 15G
User-created cable
+
Connection cable from RKC INSTRUMENT INC.
*5
W-BF-02
Cable length:
1200m or less
GP-4107 (COM1)
GP-4*03T
*6
(COM2)
GP-4203T (COM1)
15H
User-created cable
+
Connection cable from RKC INSTRUMENT INC.
*5
W-BF-02
Cable length:
1200m or less
GP4000
*7
(COM2)
GP-4201T (COM1)
SP5000 (COM1/2)
15I
RS-422 terminal block conversion adapter by Pro-face
PFXZCBADTM1
*8
+
User-created cable
+
Connection cable from RKC INSTRUMENT INC.
*5
W-BF-02
Cable length:
1200m or less
15B
User-created cable
+
Connection cable from RKC INSTRUMENT INC.
*5
W-BF-02
LT-4*01TM (COM1)
LT-Rear Module
(COM1)
15J
RJ45 RS-485 Cable (5m) by Pro-face
PFXZLMCBRJR81
+
Connection cable from RKC INSTRUMENT INC.
*5
W-BF-02
Cable length:
200m or less
*1 All GP3000 models except AGP-3302B
*2 All ST models except AST-3211A and AST-3302B
*3 All GP3000 models except GP-3200 and AGP-3302B
*4 Only the COM port which can communicate by RS-422/485 (2wire) can be used.
 IPC COM Port (page 9)
*5 To use multiple External Devices, utilize the W-BF-02 connection cable from RKC INSTRUMENT INC.
*6 Except GP-4203T
*7 All GP4000 models except GP-4100 series, GP-4*01TM, GP-4201T and GP-4*03T
*8 When using a Terminal Block Conversion Adapter (CA3-ADPTRM-01) instead of the RS-422 Terminal Block
Conversion Adapter, refer to Cable Diagram 15A.
Display
(Connection Port)
Cable Remarks
