RKC INSTRUMENT CB100 Series - Page 205

Temperature Controller Driver
GP-Pro EX Device/PLC Connection Manual
205
15E)
• 1:1 Connection
• 1:n Connection
• We recommend the TM4P-66P from HIROSE ELECTRIC CO., LTD. as the modular
connector.
• To use the External Device's COM.PORT, pair COM.PORT1 with COM.PORT2, and
COM.PORT3 with COM.PORT4.
2
1
T/R(B)
T/R(A)
3SG
RDB
SDB
SG
FG
RDA
SDA
TRM
CA3-ADPCOM-01
CA3-ADPTRM-01
COM.PORT1
or COM.PORT3
modular connector
Display
Shield
Terminal block
External Device side
Signal name
Pin
Signal name
External
Device
User-created cable
Connect the terminating
resistor connector
W-BW-01 for Z-COM
to COM.PORT2
or COM.PORT4.
Display side
2
1
T/R(B)
T/R(A)
3SG
RDB
SDB
SG
FG
RDA
SDA
TRM
CA3-ADPCOM-01
CA3-ADPTRM-01
W-BF-02
COM.PORT2
or
COM.PORT4
COM.PORT1
or
COM.PORT3
COM.PORT1
or COM.PORT3
modular connector
Display
Shield
Terminal block
External Device side
Signal name
Pin
Signal name
External
Device
User-created cable
External
Device
Connect the terminating
resistor connector
W-BW-01 for Z-COM
to COM.PORT2
or COM.PORT4.
Display side
