GP-Pro EX Device/PLC Connection Manual
222
23 N1 LBA1 deadband
24 A4 Event 4 set value
25 A6 Control loop break alarm 2 (LBA2) time
26 N2 LBA2 deadband
27 S1 Set value (SV1) of input 1
28 P1 Proportional band of input 1
29 I1 Integral time of input 1
2A D1 Derivative time of input 1
2B CA Control response parameter of input 1
2C S0 Set value (SV2) of input 2
2D P0 Proportional band of input 2
2E I0 Integral time of input 2
2F D0 Derivative time of input 2
30 C9 Control response parameter of input 2
31 HH Setting change rate limiter (up) of input 1
32 HL Setting change rate limiter (down) of input 1
33 HX Setting change rate limiter (up) of input 2
34 HY Setting change rate limiter (down) of input 2
35 TM Area soak time
36 LP Link area number
37 A7 Heater break alarm 1 (HBA1) set value
38 A8 Heater break alarm 2 (HBA2) set value
39 PB PV bias of input 1
3A F1 PV digital filter of input 1
3B PR PV ratio of input 1
3C DP PV low input cut-off of input 1
3D T0 Proportional cycle of input 1
3E ON Manual output value of input 1
3F PA PV bias of input 2
40 F0 PV digital filter of input 2
41 PQ PV ratio of input 2
42 DO PV low input cut-off of input 2
43 T2 Proportional cycle of input 2
44 OM Manual output value of input 2
45 LK Set lock level
46 EM EEPROM status
47 EB EEPROM mode
48 NE Heater break determination point 1
49 NF Heater melting determination point 1
4A NH Heater break determination point 2
4B NI Heater melting determination point 2
4C HP Not used
4D HQ Not used
4E HR Not used
4F FP Not used
50 FQ Not used
51 FR Not used
52 IL Not used
53 AZ Not used
54 FS Not used
55 DX STOP display selection
56 DA Bar graph display selection
Address Identifier Description
