RKC INSTRUMENT CB100 Series User Manual

Temperature Controller Driver
GP-Pro EX Device/PLC Connection Manual
241
33 XO AO function selection
34 OY AO corresponding channel setting
35 CV AO zooming high limit
36 CW AO zooming low limit
37 JK AO zero point correction
38 JL AO full scale correction
39 L1 DI module input status (DI-A module)
3A C2 CC-Link selecting flag
3B Q3 Event DO status (DO-C module)
3C Q4 Event DO manual output value (DO-C module)
3D A7 Event DO extension alarm set value
3E KH Cascade monitor
3F KF Cascade ON/OFF
40 KG Cascade gain
41 KI Cascade bias
42 M7 TI measured value
43 AF TI alarm 1 status
44 AG TI alarm 2 status
45 B2 TI burnout status
46 A8 TI alarm 1 set value
47 A9 TI alarm 2 set value
48 PC TI PV bias
49 EJ TI operation mode transfer
4A L3 PCP module DI status
4B L4 Event DI contact input monitor (DI-B module)
4C L5 Event DI logic input monitor
4D Q5 Event DI logic output monitor
4E AH CT module heater break alarm status
4F AJ Comprehensive alarm status
50 M8 Positioning monitor
51 V3 Positioning output neutral zone
52 TJ Motor time
53 OS Integrated output limite
54 OO Manual positioning output value
55 C1 Local/Computer transfer
56 XI Input range number [
-TIO-, H-CIO-A]
57 SH Setting limiter (high) [
-TIO-, H-CIO-A]
58 SL Setting limiter (low) [
-TIO-, H-CIO-A]
59 F1 Digital filter [
-TIO-, H-CIO-A]
5A AV Input error determination point (high) [
-TIO-, H-CIO-A]
5B AW Input error determination point (high) [
-TIO-, H-CIO-A]
5C WH Action at input error (high) [
-TIO-, H-CIO-A]
5D WL Action at input error (low) [
-TIO-, H-CIO-A]
5E GB AT bias [
-TIO-, H-CIO-A]
5F HH Setting change rate limiter (high) [
-TIO-, H-CIO-A]
60 OH
Output limiter (high) [For heat/cool control:Heat-side output limiter (high)] [
-TIO-,
H-CIO-A]
61 OL
Output limiter (low) [For heat/cool control:Cool-side output limiter (high)] [
-TIO-,
H-CIO-A]
62 IV ON/OFF control differential gap (upper) [
-TIO-, H-CIO-A]
63 IW ON/OFF control differential gap (lower) [
-TIO-, H-CIO-A]
64 OE Manipulated output value at input error [
-TIO-, H-CIO-A]
65 PH Output change rate limiter (up) [
-TIO-, H-CIO-A]
Address Identifier Description
