RKC INSTRUMENT CB100 Series User Manual

Temperature Controller Driver
GP-Pro EX Device/PLC Connection Manual
41
 Settings of External Device
Communication setting of the external device is set with the rotary switch on the front face of the temperature
controller and the dip switch in the temperature controller.
Please refer to the temperature controller manual for details.
 Procedure
1. Set module address with the rotary switch on the front face of the temperature controller.
2. Set communication speed and data bit construction with the dip switch on the side of the temperature
controller.
 Setting value
Rotary switch
Dip switch
Upper Digit Setting 0
Lower Digit Setting 0
Dip switch Setting Description
SW1 ON
Communication speed
SW2 OFF
SW3 ON
Data bit constructionSW4 OFF
SW5 OFF
SW6 OFF Protocol construction
SW7 OFF
Fixed
SW8 OFF
