Temperature Controller Driver
GP-Pro EX Device/PLC Connection Manual
87
 Settings of External Device
Communication setting of the external device is set with the slave address setting switch on the front face of the
temperature controller and the dip switch in the temperature controller.
Please refer to the temperature controller manual for details.
 Procedure
1. Set slave address for the host link with the slave address setting switch on the front face of the temperature
controller.
2. Remove the temperature controller from the mother block and set communication speed and data construction
with the dip switch in the temperature controller.
 Setting value
Slave address setting switch
Dip switch
Upper Digit Setting 0
Lower Digit Setting 0
Dip switch Setting Discription
1ON
Data construction
2ON
3ON
Communication speed
4OFF
• Parameters to be set differ per temperature controller. Please refer to the temperature controller
manual for details.
