5. COMMUNICATION IDENTIFIER
IMCB03-E4
29
Name
Iden-
tifier
Data range
Factory set
value
Attribute
Heater break alarm 1
setting
See *1.
A3
0.0 to 100.0 A 0.0 R/W
Heater break alarm 2
setting
See *2.
A4
0.0 to 100.0 A 0.0 R/W
Control loop break alarm
(LBA) setting
See *1, *3.
A5
0.1 to 200.0 min. 8.0 R/W
LBA deadband
See *1, *3.
A6
Temperature input:
0 to 9999 °C [°F]
Voltage/current inputs:
0 to 100 % of span
0R/W
Autotuning (AT)
G1
0: Autotuning (AT) end or
suspension
1: Autotuning (AT) start
*Change to "0" automatically at
the end of Autotuning.
0R/W
Self-tuning (ST)
See *5.
G2
0: Self-tuning (ST) suspension
1: Self-tuning (ST) start
0R/W
Heat-side proportional
band
P1
Temperature input:
1 (0.1) to span or
9999 (999.9) °C [°F]
Voltage/current inputs :
0.1 to 100.0 % of span
(ON/OFF action control when set
to 0 or 0.0.)
*Cannot be set while the self-tunin
g
(ST) function is activated.
Only polling can be made.
Temperature
input:
30 (30.0)
Voltage/
current
inputs: 3.0
R/W
Integral time
I1
1 to 3600 sec (0: PD control)
*Cannot be set while the self-tunin
g
(ST) function is activated.
Only polling can be made.
240 R/W
Continued on the next page.
