5. COMMUNICATION IDENTIFIER
IMCB03-E4
30
Name
Iden-
tifier
Data range
Factory set
value
Attribute
Derivative time
D1
1 to 3600 sec (0: PI control)
*Cannot be set while the self-tunin
g
(ST) function is activated.
Only polling can be made.
60 R/W
Anti-reset windup
W1
1 to 100 % of
heat-side proportional band
(0: Integral action OFF)
*Cannot be set while the self-tunin
g
(ST) function is activated.
Only polling can be made.
100 R/W
Heat-side proportioning
cycle
T0
1 to 100 sec
(Not set if the control output is
current output.)
See *6.R/W
Cool-side proportional
band
See *7.
P2
1 to 1000 % of
heat-side proportional band
100 R/W
Overlap/deadband
See *7.
V1
Temperature input:
-10 to +10 °C [°F] or
-10.0 to +10.0 °C [°F]
Voltage/current inputs:
-10.0 to +10.0 % of span
0 or 0.0 R/W
Cool-side proportioning
cycle
See *7.
T1
1 to 100 sec
(Not set if the control output is
current output.)
See *8.R/W
PV bias
PB
-span to +span
However, temperature input:
-1999 to +9999 °C [°F] or
-199.9 to +999.9 °C [°F]
0 or 0.0 R/W
Set data lock function
LK
0 to 7 See *9.0 R/W
