2
IMCB03-E3
2. WIRING
Up to 32 CB100/CB400/CB500/CB700/CB900 digital controller (hereinafter, the "controller")
including the host computer can be connected if multidrop connected by RS-485.
!
Terminal No. and signal details
CB100/CB400/CB500/CB900
Terminal No. Signal name Name
Signal direction
Controller Host computer
13 SG Signal ground
14 T/R(A) Send data/Receive data
15 T/R(B) Send data/Receive data
CB700
Terminal No. Signal name Name
Signal direction
Controller Host computer
7 SG Signal ground
8 T/R(A) Send data/Receive data
9 T/R(B) Send data/Receive data
In order to prevent electric shock or instrument failure, do not turn on the power
until all the wiring is finished.
WARNING
!
