-8-
(4) First-alarm (ALM1) type selection ( )
Set-value (SV) display unit
VALUE DESCRIPTION
No first alarm
High alarm
Low alarm Deviation First alarm (ALM1)
High / Low alarm alarm type selection
Band alarm (See page 10)
High alarm Process
Low alarm alarm
Without alarm hold action First alarm (ALM1)
With alarm hold action hold action selection
Cautions
1. The following instrument is set to “ ”.
C Instrument without the first alarm (ALM1).
C Instrument which outputs control loop break alarm (LBA) from the first alarm side. [
setting details : For “ ” ]
2. “ ” setting displays are only “ ”and “ ”.
