190 • ESM-01 Calibration EAGLE 2 Operator’s Manual
31. If you want to change the ESM-01 channel’s calibration gas value, follow
Step 15 - Step 24 above beginning with the ESM-01 Calibration Gas
Value Screen below instead of the standard channel Calibration Gas
Value Screen.
32. With the ESM-01 Calibration Gas Value Screen displayed, press and
release the POWER ENTER RESET button to proceed to the Calibration
In Process Screen for the ESM-01 channel with CAL IN PROCESS
flashing.
If you do not want to proceed with the calibration, press and release the
DISPLAY ADJUST NO button to return to the ESM-01 Cal Gas Values
Screen.
If you do want to continue with the calibration, proceed to the next step.
33. Screw the ESM-01 calibration cylinder onto the demand flow regulator.
34. Connect the tubing from the regulator to the rigid tube on the probe.
Allow the EAGLE 2 to draw gas for two minutes. If you notice that the
gas reading stabilizes sooner, you can reduce the gas application time to
the time it takes the gas reading to stabilize.
35. Press and release the POWER ENTER RESET button to set the span
adjustment for the ESM-01 channel to the programmed value.
CAL GAS VALUE
NH3 25 ppm
ENTER TO BEGIN CAL
CAL IN PROCESS
NH3 0 ppm
ENTER WHEN DONE
