266 • Parts List EAGLE 2 Operator’s Manual
16. Make sure that the top case gasket is fully seated in its groove and
carefully put the top case back on the bottom case. If you have any
difficulty mating the top and bottom cases, inspect the placement of the
main PCB and the placement of the top case gasket.
17. Turn the EAGLE 2 upside down and tighten the three case screws to
secure the top case to the bottom case.
18. Calibrate the infrared hydrocarbon channel as described in “Infrared
Hydrocarbon Calibration” on page 256.
Parts List
Table 32: Infrared HC EAGLE 2 Parts List
Part Number Description
47-5051RK Infrared HC sensor cable
DEM-3313-2 Infrared HC sensor, 0-100 %LEL/2.0-30.0 %vol autoranging
81-0018RK-01 Calibration cylinder, 50 %LEL isobutane in air, 34 liter steel
81-0018RK-03 Calibration cylinder, 50 %LEL isobutane in air, 103 liter steel
81-0019RK Calibration cylinder, 10 %volume isobutane in nitrogen, 17 liter steel
