DMX protocol
1 2
1 1 Pan
0 - 255 Pan movement by 540° (128=default) proportional
2 2
Pan Fine
0 - 255 Fine control of pan movement (0=default) proportional
3 3
Tilt
0 - 255 Tilt movement by 265° (128=default) proportional
4 4
Tilt fine
0 - 255 Fine control of tilt movement (0=default) proportional
5 5
Pan/Tilt speed , Pan/Tilt time
0 Standard mode (0=default) step
1 Max. Speed Mode step
Pan/Tilt speed mode
2 - 255 Speed from max. to min. proportional
Pan/Tilt time mode
2 - 255 Time from 0.2 s to 25.5 sec. proportional
6 6
Power/Special functions
0 - 9 Reserved (0=default)
To activate following functions , stop in DMX value for at least 3 s
and shutter must be closed (except CRI setting) at least 3 sec.
(„Shutter,Strobe” channel 37/33 must be at range: 0-31 DMX).
Corresponding menu items are temporarily overridden except DMX
Input.
10-14
DMX input: Wired DMX *
step
15-19
DMX input: Wireless DMX *
step
* function is active only10 seconds after switching the fixture on
20-24
Graphic display On
step
25-29
Graphic display Off
step
To activate CRI setting, stop in DMX value for at least 3 seconds.
30-34
High CRI (CRI=90+)
step
35-39
Standard CRI (CRI=80)
step
40-44
Eco mode ( Lamp power 380W)
step
45-49
Standard mode (Lamp power 470W)
step
50-54 Close proximity mode On step
55-59 Close proximity mode Off step
60-64
Fans mode: Auto
step
65-69
Fans mode: High
step
70-74
Dimmer curve: Square law
step
75-79
Dimmer curve: Linear
step
80-84
Autofocus On
step
85-89
Autofocus Off
step
90-94 Pan/Tilt speed mode step
95-99 Pan/Tilt time mode step
100-101 Blackout while pan/tilt moving step
102-103 Disabled blackout while pan/tilt moving step
104-105 Blackout while prism wheel 1 (wheel 2) moving step
106-107 Disabled blackout while prism wheel 1 (wheel 2) moving step
108-119 Reserved
Robin MegaPointe - DMX protocol
Version: 1.4 Mode 1-Standard 16-bit, Mode 2 -Reduced 8-bit
Mode/channel
DMX
Value
Function
Type of
control
