DMX protocol
1 2
Mode/channel
DMX
Value
Function
Type of
control
120-124 Parking position On step
125-129 Parking position Off step
To activate following functions, stop in DMX value for at least 3
seconds.
130 - 139 Lamp On step
140 - 149 Pan/Tilt reset step
150 - 159 Colour system reset step
160 - 169 Gobo wheels reset step
170 - 179 Dimmer/Shutter/Hot Spot reset step
180 - 189 Zoom/focus/frost/prism wheels reset step
190 - 199 Effect wheel reset step
200 - 209 Total reset step
210 - 229 Reserved
230 - 239 Lamp Off step
The following RoboSpot related commands are only applicable when the RoboSpot
is connected:
240 - 244 RoboSpot enabled step
245 - 249 RoboSpot disabled - except handle faders and pan/tilt step
250 - 255 RoboSpot fully disabled except pan/tilt step
7 7
Cyan
0 - 255 Cyan from min. saturation --> full cyan (0=default) proportional
8 8
Magenta
0 - 255 Magenta from min. saturation --> full magenta (0=default) proportional
9 9
Yellow
0 - 255 Yellow from min. saturation --> full yellow (0=default) proportional
10 10
Colour wheel
Continual positioning
0 Open/white (0=default) proportional
9 Deep Red proportional
18 Deep Blue proportional
27 Yellow proportional
37 Light green proportional
46 Magenta proportional
55 Lavender proportional
64 Pink proportional
73 Dark green proportional
82 CTO 2700K proportional
91 Blue proportional
101 Orange proportional
110 CTO 3200K proportional
119 UV (Kongo blue) proportional
128-129 White step
Positioning
130-134 Deep Red step
135-138 Deep Blue step
139-143 Yellow step
144-147 Light green step
148-152 Magenta step
153-157 Lavender step
158-161 Pink step
