Robe ROBIN MegaPointe Wireless DMX

To Next Page

To Previous Page

DMX protocol

1 2

Mode/channel

DMX

Value

Function

Type of

control

67-68

Filter 139 (Primary Green)

step

69-70

Filter 141 (Bright Blue)

step

71-72

Filter 147 (Apricot)

step

73-74

Filter 148 (Bright Rose)

step

75-76

Filter 152 (Pale Gold)

step

77-78

Filter 154 (Pale Rose)

step

79-80

Filter 157 (Pink)

step

81-82

Filter 158 (Deep Orange)

step

83-84

Filter 162 (Bastard Amber)

step

85-86

Filter 164 (Flame Red)

step

87-88

Filter 165 (Daylight Blue)

step

89-90

Filter 169 (Lilac Tint)

step

91-92

Filter 170 (Deep Lavender)

step

93-94

Filter 172 (Lagoon Blue)

step

95-96

Filter 179 (Chrome Orange)

step

97-98

Filter 180 (Dark Lavender)

step

99-100

Filter 181 (Congo Blue)

step

101-102

Filter 197 (Alice Blue)

step

103-104

Filter 201 (Full C.T. Blue)

step

105-106

Filter 202 (Half C.T. Blue)

step

107-108

Filter 203 (Quarter C.T. Blue)

step

109-110

Filter 204 (Full C.T. Orange)

step

111-112

Filter 205 (Half C.T. Orange)

step

113-114

Filter 206 (Quarter C.T. Orange)

step

115-116

Filter 247 (Filter Minus Green)

step

117-118

Filter 248 (Half Minus Green)

step

119-120

Filter 281 (Three Quarter C.T. Blue)

step

121-122

Filter 285 (Three Quarter C.T. Orange)

step

123-124

Filter 352 (Glacier Blue)

step

125-126

Filter 353 (Lighter Blue)

step

127-128

Filter 715 (Cabana Blue)

step

129-130

Filter 778 (Millennium Gold)

step

131-132

Filter 793 (Vanity Fair)

step

133-255

Raw DMX

proportional

13 12

Effect Speed

Speed of Cyan and Magenta and Yellow movement

0-255 Speed of CMY movement from max. to min. (0=default) proportional

14 13

CMY & Colour wheel time

0 Function is off (0=default) step

1 - 255 Time of CMY and col. wheel movement (0.1sec-->25.5sec.) proportional

15 14

Zoom & Focus & Frost & Prism time

0 Function is off (0=default) step

1 - 255 Time of zoom/ focus movement (0.1 sec-->25.5 sec.)

proportional

1-100 Time of frost movement (0.1 sec -->10 sec)

proportional

1-50

Time of prism movement (0.1 sec-->5 sec.)

proportional

16 15

Effect wheel positioning

0-19 No function (0=default) step

20-127 Proportional indexing proportional

128-170 Ramping from open to full position ( max--->min. speed) proportional

Page 4
