DMX protocol
1 2
Mode/channel
DMX
Value
Function
Type of
control
171-213 Ramping from open to half position ( max. --->min. speed) proportional
214-255 Ramp. from half position to full position ( max. --->min. speed) proportional
17 16
Effect wheel rotation
0 No rotation step
1 - 127 Forwards rotation from fast to slow proportional
128 No rotation (128=default) step
129 -255 Backwards rotation from slow to fast proportional
18 17
Effect wheel animations
0-3 No animation (0=default)
Note :
Set suitable DMX value at
Focus
channel to get desired
animation. All animations were created at distance 5 m from
screen with zoom=6 DMX
Coloured animations.
The channels are blocked: CMY , Colour
wheel, Virtual colour wheel, Effect wheel positioning, Effect wheel
rot., Stat. Gobo, Rotat. Gobo, Prism. wheel 1 (2)
4-5 Animation Macro 1 step
6-7 Animation Macro 2 step
8-9 Animation Macro 3 step
10-11 Animation Macro 4 step
12-13 Animation Macro 5 step
14-15 Animation Macro 6 step
16-17 Animation Macro 7 step
18-19 Animation Macro 8 step
20-21 Animation Macro 9 step
22-23 Animation Macro 10 step
Black and white animations
. The channels are blocked: Effect
wheel positioning, Effect wheel rotation, Stat. Gobo, Rotat. Gobo,
Prism. wheel 1 (2)
24-25 Animation Macro 1 step
26-27 Animation Macro 2 step
28-29 Animation Macro 3 step
30-31 Animation Macro 4 step
32-33 Animation Macro 5 step
34-35 Animation Macro 6 step
36-37 Animation Macro 7 step
38-39 Animation Macro 8 step
40-41 Animation Macro 9 step
42-43 Animation Macro 10 step
44-255 Raw DMX proportional
19 18
Static gobo wheel
0-3 Open/Hole (0=default) step
Positioning
4-9 Gobo 1 step
10-15 Gobo 2 step
16-21 Gobo 3 step
22-27 Gobo 4 step
28-33 Gobo 5 step
34-39 Gobo 6 step
40-45 Gobo 7 step
46-51 Gobo 8 step
52-57 Gobo 9 step
