DMX protocol
1 2
Mode/channel
DMX
Value
Function
Type of
control
58-63 Gobo 10 step
64-69 Beam reducer 1 step
70-75 Beam reducer 2 step
76-81 Beam reducer 3 step
82-87 Beam reducer 4 step
Shaking gobos from slow to fast
88-95 Gobo 1 proportional
96-103 Gobo 2 proportional
104-111 Gobo 3 proportional
112-119 Gobo 4 proportional
120-127 Gobo 5 proportional
128-135 Gobo 6 proportional
136-143 Gobo 7 proportional
144-151 Gobo 8 proportional
152-159 Gobo 9 proportional
160-167 Gobo 10 proportional
168-175 Beam reducer 1 proportional
176-183 Beam reducer 2 proportional
184-191 Beam reducer 3 proportional
192-199 Beam reducer 4 proportional
200-201 Open/hole step
202 - 222 Forwards gobo wheel rotation from fast to slow proportional
223 - 243 Backwards gobo wheel rotation from slow to fast proportional
244 - 249 Random gobo selection by audio control step
(Set microphone sensitivity in menu „Personality”)
250 - 255 Auto random gobo selection from fast to slow proportional
20 19
Index - set indexing on channel 21/20
0 Open/Hole (0=default) step
1-4 Hole (flat field) step
5-7 Gobo 1 step
8-10 Gobo 2 step
11-13 Gobo 3 step
14-16 Gobo 4 step
17-19 Gobo 5 step
20-22 Gobo 6 step
23-25 Gobo 7 step
26-28 Gobo 8 step
29-31 Gobo 9 step
Rotation - set rotation on channel 21/20
32-34 Gobo 1 step
35-37 Gobo 2 step
38-40 Gobo 3 step
41-43 Gobo 4 step
4-46 Gobo 5 step
47-49 Gobo 6 step
50-52 Gobo 7 step
53-55 Gobo 8 step
56-59 Gobo 9 step
Page 6
