DMX protocol
1 2
Mode/channel
DMX
Value
Function
Type of
control
Shaking gobo from slow to fast
Index - set indexing on channel 21/20
60-67 Gobo 1 proportional
68-75 Gobo 2 proportional
76-83 Gobo 3 proportional
84-91 Gobo 4 proportional
92-99 Gobo 5 proportional
100-107 Gobo 6 proportional
108-115 Gobo 7 proportional
116-123 Gobo 8 proportional
124-129 Gobo 9 proportional
Shaking gobo from slow to fast
Rotation - set rotation on channel 21/20
130-137 Gobo 1 proportional
138-145 Gobo 2 proportional
146-153 Gobo 3 proportional
154-161 Gobo 4 proportional
162-169 Gobo 5 proportional
170-177 Gobo 6 proportional
178-185 Gobo 7 proportional
186-193 Gobo 8 proportional
194-199 Gobo 9 proportional
200 - 201 Open/hole step
202 - 222 Forwards gobo wheel rotation from fast to slow proportional
223 - 243 Backwards gobo wheel rotation from slow to fast proportional
244 - 249 Random gobo selection by audio control step
(Set microphone sensitivity in menu „Personality”)
250 - 255 Auto random gobo selection from fast to slow proportional
21 20
Rot. gobo indexing and rotation
Gobo indexing - set position on channel 20/19
0 - 255 Gobo indexing proportional
Gobo rotation - set position on channel 20/19
0 No rotation step
1 - 127 Forwards gobo rotation from fast to slow proportional
128 No rotation (128=default) step
129 - 255 Backwards gobo rotation from slow to fast proportional
22 *
Rot. gobo indexing/rotation - fine
0-255 Fine indexing/rotation (0=default) proportional
23 21
This wheel is blocked If Rotating gobo wheel >0 DMX
0 - 3 Open position/hole (0=default) step
Index - set indexing on channel 24/22
4-7 Prism 1 - 6-facet linear step
8-11 Prism 2 - cylindrical step
12-15 Prism 3 - 8-facet 12° circular step
Rotation - set rotation on channel 24/22
16-19 Prism 1 - 6-facet linear step
20-23 Prism 2 - cylindrical step
24-27 Prism 3 - 8-facet 12° circular step
