DMX protocol
1 2
Mode/channel
DMX
Value
Function
Type of
control
28-255 Raw DMX proportional
24 22
Prism wheel 1 indexing/rotation
Prism indexing - set position on channel 23/21
0 - 255 Prism 1 indexing proportional
Prism 1 rotation - set position on channel 23/21
0 No rotation step
1 - 127 Forwards prism rotation from fast to slow proportional
128 No rotation (128=default) step
129-255 Backwards prism rotation from slow to fast proportional
25 23
0 - 3 Open position/hole (0=default) step
Index - set indexing on channel 26/24
4-7 Prism 1 - 6-facet linear step
8-11 Prism 2 - 32-facet circular step
12-15 Prism 3 - 8-facet 18° circular step
Rotation - set rotation on channel 26/24
16-19 Prism 1 - 6-facet linear step
20-23 Prism 2 - 32-facet circular step
24-27 Prism 3 - 8-facet 18° circular step
28-255 Raw DMX proportional
26 24
Prism wheel 2 indexing/rotation
Prism indexing - set position on channel 25/23
0 - 255 Prism 1 indexing proportional
Prism 1 rotation - set position on channel 25/23
0 No rotation step
1 - 127 Forwards prism rotation from fast to slow proportional
128 No rotation (128=default) step
129-255 Backwards prism rotation from slow to fast proportional
27 25
The channels are blocked: Prism Wheel 1/2, Prism Wheel 1/2 rot.
0-3 Open position/hole (0=default) step
Index - set indexing on channel 28/26
4-5 Pattern 1 step
6-7 Pattern 2 step
8-9 Pattern 3 step
10-11 Pattern 4 step
12-13 Pattern 5 step
14-15 Pattern 6 step
16-17 Pattern 7 step
18-19 Pattern 8 step
20-21 Pattern 9 step
22-23 Pattern 10 step
24-25 Pattern 11 step
26-27 Pattern 12 step
Rotation - set rotation on channel 28/26
28-29 Pattern 1 step
30-31 Pattern 2 step
32-33 Pattern 3 step
34-35 Pattern 4 step
