DMX protocol
1 2
Mode/channel
DMX
Value
Function
Type of
control
36-37 Pattern 5 step
38-39 Pattern 6 step
40-41 Pattern 7 step
42-43 Pattern 8 step
44-45 Pattern 9 step
46-47 Pattern 10 step
48-49 Pattern 11 step
50-51 Pattern 12 step
Dynamic patterns-set rotation on channel 28/26
52-53 Pattern 13 step
54-55 Pattern 14 step
56-57 Pattern 15 step
58-59 Pattern 16 step
60-61 Pattern 17 step
62-63 Pattern 18 step
64-65 Pattern 19 step
66-67 Pattern 20 step
68-255 Raw DMX proportional
28 26
Pattern rotation and indexing
The channels are blocked: Prism Wheel 1/2, Prism Wheel 1/2 rot.
Pattern indexing - set position on channel 27/25
0 - 255 Pattern indexing proportional
Pattern rotation - set position on channel 27/25
0 No rotation step
1 - 127 Forwards pattern rotation from fast to slow proportional
128 No rotation (128=default) step
129-255 Backwards pattern rotation from slow to fast proportional
29 27
Beam shaper selection
The channels are blocked: Pris.Wheel 1 and 2, Static gobo, Rotating
gobo, Frost ( Light frost only)
0 - 3 Open position/hole (0=default) step
Index - set indexing on channel 30/28
4-7 Beam shaper 1 step
8-11 Beam shaper 2 step
12-15 Beam shaper 3 step
16-19 Beam shaper 4 step
Rotation - set rotation on channel 30/28
20-23 Beam shaper 1 step
24-27 Beam shaper 2 step
28-31 Beam shaper 3 step
32-35 Beam shaper 4 step
36-255 Reserved
30 28
Beam shaper rotation and indexing
Beam shaper indexing - set position on channel 29/27
0 - 255 Shaper indexing proportional
Beam shaper rotation - set position on channel 29/27
0 No rotation step
1 - 127 Forwards shaper rotation from fast to slow proportional
128 No rotation (128=default) step
129-255 Backwards shaper rotation from slow to fast proportional
