DMX protocol
1 2
Mode/channel
DMX
Value
Function
Type of
control
31 29
Frost
0 Open (0=default) step
Light Frost
Max. time of Light frost movement 0 -->100% (100% -->0) is 10 sec.
1-50 Light Frost from 0% to 100% proportional
51-53 100% Light Frost step
54-63 Pulse closing from slow to fast proportional
64-73 Pulse opening from fast to slow proportional
74-83 Ramping from fast to slow proportional
84-86 Open step
Medium Frost
Max. time of Medium frost movement 0 -->100% (100% -->0) is 10 sec.
87-136 Medium Frost from 0% to 100% proportional
137-139 100% Medium Frost step
140-149 Pulse closing from slow to fast proportional
150-159 Pulse opening from fast to slow proportional
160-169 Ramping from fast to slow proportional
170-172 Open step
Frost Combined
Max. time of Medium frost movement 0 -->100% (100% -->0) is 10 sec.
173-222 Medium Frost from 0% to 100% (Light Frost inserted) proportional
223-225 100% Medium Frost (Light Frost inserted) step
226-235 Pulse closing from slow to fast (both frosts together) proportional
236-245 Pulse opening from fast to slow (both frosts together) proportional
246-255 Ramping from fast to slow (both frosts together) proportional
32 30
Zoom
0 - 255 Zoom from max. to min.beam angle (128=default) proportional
33 *
Zoom - fine
0-255 Fine zooming (0=default) proportional
34 31
Focus
0 - 255 Continuous adjustment from far to near (128=default) proportional
35 *
Focus Fine
0- 255 Fine focusing (0=default) proportional
36 32
Hot-Spot control
0 Automatic Hot-Spot control (0=default) step
1-255 Hot-Spot control (from min. to max. intensity of image centre) proportional
37 33
Shutter/ strobe
0 - 31 Shutter closed step
32 - 63 Shutter open (32=default) step
64 - 95 Strobe-effect from slow to fast proportional
96 - 127 Shutter open step
128 - 143 Opening pulse in sequences from slow to fast proportional
144 - 159 Closing pulse in sequences from fast to slow proportional
160 - 191 Shutter open step
192 - 223 Random strobe-effect from slow to fast proportional
224 - 255 Shutter open, Full lamp power step
38 34
Dimmer intensity
0 - 255 Dimmer intensity from 0% to 100% (0=default) proportional
39 *
Dimmer intensity - fine
