Robertshaw RS9110 User Manual

Tech Settings LCD Will Show Adjustment Options Default
Compressor
Short Cycle
Delay
The compressor short cycle delay
protects the compressor from short
cycling. This feature will not allow
the compressor to be turned on for 5
minutes after it was last turned off.
Next step
Prev step
Selecting ON will not allow the
compressor to be turned on for
5 minutes after the last time the
compressor was switched off.
Select OFF to remove this delay.
ON
Cooling
Differential
or Swing
The differential setting, often called
cycle rate or anticipation, is adjustable.
A smaller differential setting will
cause more frequent cycles and a
larger differential setting will cause
fewer cycles.
Next step
Prev step
The cooling differential setting
is adjustable from 0.2° to 2°. For
example: A differential setting
of 0.5° will turn the cooling on
at approximately 0.5° above the
setpoint and turn the cooling off
at approximately 0.5° below the
setpoint.
0.5
Heating
Differential
or Swing
The differential setting, often called
cycle rate or anticipation, is adjustable.
A smaller differential setting will
cause more frequent cycles and a
larger differential setting will cause
fewer cycles.
Next step
Prev step
The heating differential setting
is adjustable from 0.2° to 2 . For
example: A differential setting
of 0.5° will turn the heating on
at approximately 0.5° below the
setpoint and turn the heating off
at approximately 0.5° above the
setpoint.
0.4
TECHNICIAN SETUP MENU
13
