Robertshaw RS9110 - Terminal Designations

RH .............. 24VAC Heating
RC .............. 24VAC Cooling
C ................. Common 24VAC (system power supply)
W ................ HEAT
Y ................. COOL
G ................. FAN
B ................. REV VALVE HEAT
O ................. Cooling Activated Reversing Valve
TERMINAL DESIGNATIONS
16
