Table 1 
Switch Off On
Sw1–FanSpeeds 1SpeedFan
(2 Heat / 2 Cool)
3SpeedFan
(1 Heat / 1 Cool)
Sw2–EquipmentType Heat / Cool Heat Pump
(O/B terminals)
Sw3–Stages 1Stage 2Stages
Sw4–ReversingValve
IfSw2=ON–HeatPump Energize in cool (O) Energize in heat (B)
Sw4–FanMode
IfSw2=OFF–Heat/cool Fan Control by
Heater (HG)
Fan Control by
Thermostat (HE)
Sw5–Anti-CycleTimer Off 4 Minutes
Sw6–Operation Manual Thermostat Programmable
Thermostat
Sw7–MinimumRun 2 Minutes 6 Minutes
Sw8–ProgramType
IfSw6=ON–Programmable Commercial Program Residential Program
Sw8–Setpoints
IfSw6=OFF–Manual SingleSetpoint TwoSetpoints
