5-4-24
AIR
CLEANER
Install cleaner base on studs, install bracket, cleaner.
Tighten the clamp for stop switch wire together with cleaner bracket
on
crankcase side.
Tightening Torque
:
EH30V,
34V
70-90kg- cm
Cleaner Base
6
4
Nut
*-*-
2pcs.
EH43V
Bracket Cleaner
6
q5
X
20mm Bolt
0-
lpce.
6
q5
X
lOmm Bolt
***-
lpce.
5-4-25
GOVERNOR
ADSUSTMENT
For
correct carburetor throttle opening and
governor regulation, the govenor lever must be
properly adjusted.
(1)
Install throttle lever control linkage on
governor lever and choke shaft control rod
in choke lever.
(2)
Hook spring
from
control bracket hole
(A)
to the hole (1,
2,
3)
in governor lever as
shown in Fig.
62.
Install bracket assembly
on
crankcase.
(3)
Install governor lever on governor shaft but
do
not tighten clamp screw.
(4)
Turn governor lever clockwise until throttle
valve in carburetor is opened fully. Hold
lever in this position.
IMPORTANT
:
Check
that
governor lever
damp
screw
is
loose
so
governor shaft can
be
turned independently
of
lever.
(5)
Insert a screwdriver in slot at end of
governor shaft. Turn clockwise
as
far as
shaft can be turned. Tighten governor lever
clamp screw.
1
10- 130kg- cm
EH43V
(3)
-
(A)
Fig.
62
I
Fig.
63
-
39
-
