Robomow MC300 User Manual

20
4.3.3 Setting a Narrow Pass
A Narrow Pass is dened as a path that connects two zones of the lawn. The path enables Robomow to drive
between the zones while following the wire, but prevents the mower from crossing between them while mowing
the inner area of the zones.
To set up a Narrow Pass follows the instructions given in the gure below:
The above setup allows Robomow to drive along the wire to reach the Sub-Zone. However, while mowing each
zone individually, it will not cross over to the other zone.
Main Zone
A. At the point you want the mower to start
driving towards the Sub-Zone start to
set the Narrow Pass.
B. 50 cm (20 inches) from the Narrow
Pass entry, set a Perimeter Island
(refer to 4.2.4) of 30 cm sides (12
inches) at a distance of 10 cm (4
inches) from the Perimeter Wire.
C. Continue to lay the wire towards the
Sub-Zone and lay another Island
with the same dimensions, 50 cm (20
inches) from the Sub-Zone Perimeter
Wire.
D. After completing the setup of the wire
in the Sub-Zone, make sure you keep
10 cm (4 inches) between the wire
and the islands on the way back to the
Main Zone.
Sub-Zone
Perimeter Island
30x30 cm
Perimeter Island
30x30 cm

Robomow MC300 Specifications

General

Type	Robotic lawn mower
Cutting width	280 mm
On/off switch	Yes
Cutting system	-
Recommended lawn area	300 m²
Maximum cutting height	60 mm
Minimum cutting height	15 mm
Grass collecting volume	- L
Battery type	LiFePO4
Power source	Battery
Battery voltage	26 V
Battery technology	Lithium

Weight and Dimensions

Depth	460 mm
Width	630 mm
Height	210 mm
Weight	11100 g
