Minimum clearance
In order to allow easy access to the boiler for
maintenance, operation, the boiler must be in accordance
with the clearances stated below.
The following minimum distance should
be left for equipment’s installation and
maintenance.
- Distance on the bottom:300mm
- Distance on the side position:5mm
- Distance on the top:300mm
- Distance on the front :500mm
5
300
300
5
